Самосвал камион HOWO 8 x 4 EXPORT

NOTE; CLASS 3 THE BEST FACTORY REBUILD UNITS!

LIKE NEW ONES!

ALL 12 PCS NEW TIRES

ENGINE AND AXLES REBUILD

ALL LUBRICATION DONE, ALL OILS ENGINE, GEAR BOX AND AXLES CHANGED

PAINTED RED

BRAND NEW CARGO BOX

BRAKES ARE NEW

CABIN; BRAND NEW SEATS AND INTERIOR ETC.

T H E TRUCK IS LIKE NEW, ONLY PRICE IS "SECOND HAND"!

MINIUM ORDER QUANTITY IS 3 PCS / SHIPPING

Model HOWO 8X4 USED DUMP TRUCK

Gross weight kg 33000

Curb weight (kg) 15450

Engine 375HP

Cab HW76

Number of axle 4

Van dimension

(mm) 7800*2300*1500

26.91M3

China Front Tipping hydraulic lifting cylinder

Thickness: floor 8mm /side 6mm

Color Red

Overall Dimension

L X W X H mm)

11000×2496×3600

SPECIFICATION OF HOWO 8X4 DUMP TRUCK

Body

Inner Dimensions(mm) 7300x2300x1500

Cubage (m3) 25

Steel thickness of Carriage(mm)

Floor:10mm/Side:8mm

Floor:8mm/Side:6mm

Steel

Q235/Q345/700/NM450

Hydraulic Lift of Carriage

Front Lift

Wheel base (mm)

1800+3500+1350

Performance

Maximum driving speed (km/h) 75

Fuel consumption (1/100 km)

-

SINOTRUK HW76 Lengthen cab

single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner

Engine Model

WD615.47（Euro 2）

Type 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection

Horsepower 371

Maximum output Kw/r/min 273/2200

Maximum torque N.m/r/min 1460/1300-1600

Bore x Stroke 126x130mm

Valve 2

Displacement 9.726L

Make by SINOTRUCK (CNHTC), Euro II emission standard

Transmission

SINOTRUK HW19710 transmission ,10 forward and 2 reverse

Clutch SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance

Steering ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)

Front Axle SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes.

Rear Axles SINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:4.8;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.

Brake System

Service brake:dual circuit compressed air brake

Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

Wheels & Tyres

Rims:8.5-20,10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.

Electrics Operating voltage:24V,negative grounded

Starter:24V,7.5 Kw

Alternator:3-phase,28V,1500 W

Batteries:2x12 V,165 Ah

horn,headlamps,fog lights,brake lights,indicators and reverse light

Oil Tank Square type-300L Aluminum alloy fuel tank
